$4.23
Original: $14.11
-70%Phoenix Contact MC 15/ 7-STF-35 Pluggable Terminal Block 3.5 mm 7 Ways 28AWG to 16AWG 1.5 mm² Screw 8 A—
$14.11
$4.23The Story
The MC 1,5/ 7-STF-3,5 from Phoenix Contact is a 3.5mm pitch, 7 pole pluggable terminal block with screw flange. The plug-in direction parallel to the conductor axis with wire size ranging from 28AWG to 16AWG.
- Nominal current is 8A
- Rated voltage (III/3) is 250V, (III/2) is 320V, (II/2) is 400V
- Rated surge voltage (III/3) is 4KV, (III/2) is 4KV, (II/2) is 4KV
- Green colour polyamide insulating material, flammability rating according to UL94 V0
- Nominal cross section is 1.5mm²
- Contact surface is tin
- Stripping length is 7mm
- CSA, VDE, CCA, cULus standards
- Screw connection with tension sleeve
- Screwable flange for superior mechanical stability
Industrial
Other details
| Brand | PHOENIX CONTACT |
| Part Number | MC 1,5/ 7-STF-3,5 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
